Azremi Abdullah Al-Hadi
Thumbnail Image
Preferred name
Azremi Abdullah Al-Hadi
Official Name
Azremi, Abdullah Al-Hadi
Alternative Name
Abdullah Al-Hadi, Azremi
Al-Hadi, Azremi A.
Al-Hadi, A. A.
Azremi, A. A. H.
Main Affiliation
Scopus Author ID
57194469675
Researcher ID
A-6983-2015

Research Output

Filters

1 1
11
Reset filters

Settings
Now showing 1 - 10 of 11
  • Publication
    User Influence on Mobile Terminal Antennas: A Review of Challenges and Potential Solution for 5G Antennas
    ( 2018)
    Rizwan Khan
    ;
    Azremi Abdullah Al-Hadi
    ;
    Ping Jack Soh
    ;
    Muhammad Ramlee Kamarudin
    ;
    Mohd Tarmizi Ali
    This paper presents a comprehensive review of mobile terminal antenna researches performed in the past seven years and the current challenges related to the user's influence on the performance of fifth generation (5G) terminal antennas. The main challenges for the designing of mobile terminal antennas are to meet the compact size requirements of built-in structures and their multiband capabilities. The antenna design techniques that are used to achieve broader operating bandwidths with smaller antenna dimensions will be first discussed. This is followed by the effects of user interactions with the head/hand for mobile antennas in terms of radiation efficiency and, consequently, the correlation of multiple input multiple output (MIMO) antenna systems. The ultimate aims of this paper are as follows: 1) to highlight the different frequencies of mobile terminal antennas for different applications; 2) to highlight mobile terminal antennas that have been developed for 5G application; 3) to study and discuss the effects of user's hand on 5G mobile terminal antennas; and 4) to discuss the research gap, issues, and challenges in the field of user's effects on mobile terminal antennas for 5G applications. In addition to that, an investigation of the users' hand effects on two MIMO mobile terminal antennas operational in the sub-6-GHz 5G band is presented. This investigation performed using two MIMO antennas is an attempt to formulate guidelines on efficient mobile terminal antenna design in the presence of user's hand in C Band (from 3.4 to 3.6 GHz) and LTE-U Band 46 (from 5.15 to 5.925 GHz).
  • Publication
    Dual Band Planar Inverted F Antenna (PIFA) with L-Shape Configuration
    ( 2017)
    Mohamad khlouf Munzer
    ;
    Saidatul Norlyana Azemi
    ;
    Ping Jack Soh
    ;
    Azremi Abdullah Al-Hadi
    ;
    Mohd Faizal Jamlos
    One of the most used antennas in mobile devices is planar inverted F antenna (PIFA). PIFA can be design in dual band frequencies due to the coverage of the wireless service in a mobile device that requires a multiple frequencies. However, the consideration of technical operation has to be combined with an evaluation of the antenna radiation impact on the users. A procedure of PIFA work in GSM (867-960MHz) and GSM (1710-1899MHz) is done using CST Software. The dual band frequency response is obtained by means of an insertion of an L-shaped slot, which is use to tune the operation frequencies. The prototype of the antenna is fabricated as model by CST Software and evaluated. It is found out that the PIFA antenna has a good efficiency, bandwidth as well as produce a maximum gain for the antenna. A key and innovative research is still underway to broaden performance parameters of the antenna.
  • Publication
    Dynamic web-based knowledge management system (KMS) in small scale agriculture
    ( 2024-02-08)
    Ong R.J.
    ;
    Suhizaz Sudin
    ;
    Rafikha Aliana A Raof
    ;
    Choong K.Y.
    ;
    Azremi Abdullah Al-Hadi
    ;
    Yacob Y.
    ;
    Nasir S.N.B.M.
    The shift from paper-based to web-based practice is a significant trend, as paper-based practice consumes time, is prone to error, and is more prone to data loss, all of which lead to inefficiency. Smart farming or agriculture 4.0 defined the new era of agriculture that moving toward digitalization. However, the absence of a centralized information system, which results in information asymmetry among agricultural sectors. One of the keys to success is reaching out to farmers with pertinent agricultural information at the appropriate time and platform. The purpose of this study is to design and create a dynamic web-based knowledge management system for the dissemination of agricultural knowledge in Malaysia. A centralized information system capable of achieving information symmetry, in which all important information is accessible to all participants. Creating an advanced learning environment allowing for virtual engagement between external and internal stakeholders via a web-based knowledge management system.
  • Publication
    Gain Optimization of Low-Profile Textile Antennas Using CMA and Active Mode Subtraction Method
    ( 2021)
    Bashar Bahaa Qas Elias
    ;
    Ping Jack Soh
    ;
    Azremi Abdullah Al-Hadi
    ;
    Prayoot Akkaraekthalin
    This paper presents an active mode subtraction method based on the characteristic mode analysis to estimate the forward directivity based on the difference in modal significance curves. This made the optimization of the antenna gain in the design process to be more efficient. To the best of the authors' knowledge, such method is innovative and proposed in literature for the first time. This method is derived on the basis that the total radiated field of the antenna, and consequently, the directivity is mainly contributed by the excited dominant modes. To demonstrate its effectiveness, three compact, planar, and wearable antennas with increasing complexity will be designed and optimized using this method. The first is a conventional circular patch antenna operating at 5.3 GHz, whereas the second one is a planar loop antenna operating at 3.08 GHz. The third design is a crown-shaped planar antenna (CPA) with a 3 × 3 artificial magnetic conductor (AMC) plane integrated underneath to reduce potential coupling effects from the body. All three antennas are made fully using textiles with the same thicknesses: felt fabric as its substrate and ShieldIt Super as its conductive textile. For all designs, the use of the proposed method, which is validated using the method of moments, has predicted the maximum direction of radiation and its respective gain at the desired frequencies with good accuracy. Besides that, the design of the AMC plane for the CPA is also optimized using CMA prior to the integration with the antenna and a leather wrist strap. Measurements of the final crown-shaped antenna design indicated a good agreement with simulations, with an operating bandwidth of more than 240 MHz, FBR of 15.73 dB and a directional radiation pattern outward from the body.
  • Publication
    Deployable Linear-to-Circular Polarizer Using PDMS Based on Unloaded and Loaded Circular FSS Arrays for Pico-Satellites
    ( 2019)
    Hidayath Mirza
    ;
    Toufiq Md Hossain
    ;
    Ping Jack Soh
    ;
    Mohd Faizal Jamlos
    ;
    Muhammad Nazrin Ramli
    ;
    Azremi Abdullah Al-Hadi
    ;
    Emad S. Hassan
    ;
    Sen Yan
    In this paper, flexible and deployable double-sided linear-to-circular polarizers designed on polydimethylsiloxane are proposed for the first time to the best of our knowledge. ShieldIt textile is used as the conducting element of the two designs based on two different unit cell arrays: a loaded circular patch unit cell or an unloaded circular patch unit cell, both backed by a generic rectangular element on its reverse side. This is in contrast to conventional frequency-selective structure-based linear-to-circular polarizers implemented using rigid substrates, which are multi-layered and requires inter-layer physical spacing. This complicates their implementation using flexible substrates and in a deployable format. Upon implementation of this double-sided polarizer, their final performances are evaluated in terms of the phase difference, conversion efficiency, 3-dB axial ratio (AR), and ellipticity bandwidth (from 40° to 45°). Measurements indicated good agreements with simulations, and both structures exhibited more than 90% of conversion efficiency from 2.34 to 3 GHz (for the loaded circular unit cell) and from 2.36 to 3 GHz (for the unloaded circular unit cell). In terms of ellipticity, a bandwidth of 8.67% is observed for the unloaded design and 13.82% for the loaded design. The unloaded structure exhibited a fractional 3-dB AR bandwidth of 36.36% (from 1.98 to 2.86 GHz) in simulations, and 32.64 % (from 2.00 to 2.78 GHz) when evaluated experimentally. Conversely, the loaded design showed only 12.58%. An equivalent circuit model is proposed and validated via a comparison between the circuit and full-wave simulations. Finally, the performances of these polarizers are also assessed under different bending conditions due to the use of flexible materials, prior to the proposal of a suitable deployment mechanism.
  • Publication
    Intelligent irrigation system using rain water harvesting system and fuzzy interface system
    ( 2021-12)
    Azremi Abdullah Al-Hadi
    ;
    Sukhairi Sudin
    ;
    Ahmad Z.A
    ;
    Fathinul Syahir Ahmad Sa'ad
    ;
    I Ahmad
    ;
    Fadhilnor Abdullah
    ;
    Wan Mohd Faizal Wan Nik
    ;
    A. Deraman
    ;
    N. M Maliki
    ;
    S R S Kamaruzaman
    ;
    S R Romle
    Shortage of water has become a predominant problem all over the world as water plays an important role in agriculture, domestic and industry. In certain parts of the world, farmers face problems watering their crops especially during the dry season. Limited water resources with low efficiency greatly affect crop growth. Therefore, this study proposes an intelligent irrigation system using Rain Water Harvesting (RWH) and Fuzzy Interface System (FIS) for crops watering process. The RWH is a system that collects, centralises and stores rainwater, while the FIS uses temperature and soil moisture sensors to determine the time and amount needed for the watering process. Thus, the intelligent irrigation system will ensure the process of watering the crops to be efficient. The results of this study show that FIS can analyse temperature and soil moisture data, which improves the efficiency of crops watering process and the use of RWH will make it sustainable. The developed project is currently operating at the Institute of Sustainable Agro Technology, i.e. a university-owned agricultural research institute.
  • Publication
    A Review of Antennas for Picosatellite Applications
    ( 2017)
    Abdul Halim Lokman
    ;
    Ping Jack Soh
    ;
    Saidatul Norlyana Azemi
    ;
    Herwansyah Lago
    ;
    Symon K. Podilchak
    ;
    Suramate Chalermwisutkul
    ;
    Mohd Faizal Jamlos
    ;
    Azremi Abdullah Al-Hadi
    ;
    Prayoot Akkaraekthalin
    ;
    Steven Gao
    Cube Satellite (CubeSat) technology is an attractive emerging alternative to conventional satellites in radio astronomy, earth observation, weather forecasting, space research, and communications. Its size, however, poses a more challenging restriction on the circuitry and components as they are expected to be closely spaced and very power efficient. One of the main components that will require careful design for CubeSats is their antennas, as they are needed to be lightweight, small in size, and compact or deployable for larger antennas. This paper presents a review of antennas suitable for picosatellite applications. An overview of the applications of picosatellites will first be explained, prior to a discussion on their antenna requirements. Material and antenna topologies which have been used will be subsequently discussed prior to the presentation of several deployable configurations. Finally, a perspective and future research work on CubeSat antennas will be discussed in the conclusion.
  • Publication
    Narrowband to Narrowband Frequency Tunable Slotted Dipole Antenna
    ( 2021-03-01)
    Rabbil Izziety Mohd Rodi
    ;
    Mohamed Nasrun Osman
    ;
    Mohammad Kamal Abd Rahim
    ;
    Muzammil Jusoh
    ;
    Thennarasan Sabapathy
    ;
    Azremi Abdullah Al-Hadi
    ;
    Soh Ping Jack
    In this paper, the slotted dipole antenna structure is proposed to have four narrowband frequencies with ability to be reconfigured. Narrowband reconfiguration can be achieved by controlling the length of slotted dipole by using switches. The narrowband frequency is to be at 1.8 GHz (GSM), 2.4 GHz (WLAN), 2.6 GHz (4G), and 3.5 GHz (5G) respectively. The longest dipole length produced 1.8 GHz, the second-longest dipole length produced 2.4 GHz, the third-longest dipole length produced 2.6 GHz, while the smallest dipole length produced 3.5 GHz. To maintain the stability of the RF current in the system, sixteen capacitors were used. As well eight inductors were used to isolate the RF current and power supply. The PIN diode was used as a switch to allow the induced current to stop and pass into the slot which means that it can be used to select the desired frequency. Depending on switching configuration, the operating frequency is tuned. Good matching is achieved for all configurations. The simulated result of gain for the four operating is higher than 2 dB while the omnidirectional radiation pattern has been obtained thus makes the proposed antenna suitable for wireless application.
      6  1
  • Publication
    A Hybrid Mutual Coupling Reduction Technique in a Dual-Band MIMO Textile Antenna for WBAN and 5G Applications
    ( 2021-01-01)
    Hamza A. Mashagba
    ;
    Hasliza A Rahim @ Samsuddin
    ;
    Ismahayati Adam
    ;
    Jamaluddin M.H.
    ;
    Mohd Najib Mohd Yasin
    ;
    Muzammil Jusoh
    ;
    Thennarasan Sabapathy
    ;
    Abdulmalek M.
    ;
    Azremi Abdullah Al-Hadi
    ;
    Arif Mawardi Ismail
    ;
    Soh Ping Jack
    This paper presents a hybrid mutual coupling reduction technique applied onto a dual-band textile MIMO antenna for wireless body area network and 5G applications. The MIMO antenna consists of two hexagonal patch antennas, each integrated with a split-ring (SR) and a bar slot to operate in dual-band mode at 2.45 GHz and 3.5 GHz. Each patch is dimensioned at 47.2 × 31 mm2. This hybrid technique results in a simple structure, while enabling significant reduction of mutual coupling (MC) between the closely spaced patches (up to 0.1 λ). This technique combines a line patch and a patch rotation technique, explained as follows. First, a line patch is introduced at an optimized distance to enable operation with a broad impedance bandwidth at both target frequencies. One of the patches is then rotated by 90° at an optimized distance, resulting in a significant MC suppression while maintaining the dual and broad impedance bandwidth. The proposed MIMO antenna is further evaluated under several bending configurations to assess its robustness. A satisfactory agreement between simulated and measured results is observed in both planar and bending conditions. Results show that the MIMO antenna achieves an impedance bandwidth of 4.3 % and 6.79 % in the 2.45 GHz and 3.5 GHz band, respectively. Moreover, very low MC (S21 <-30 dB) is achieved, with a low (< 0.002) envelop correlation coefficient, and about 10 dB of diversity gain at both desired frequencies using this technique. Even when bent at an angle of 50° at the x-and y-axes, the antenna bent maintained a realized gain of 1.878 dBi and 4.027 dBi in the lower and upper band, respectively. A robust performance is offered by the antenna against the lossy effects of the human body with good agreements between simulated and measured results.
      1
  • Publication
    Compact Multiband Reconfigurable MIMO Antenna for Sub- 6GHz 5G Mobile Terminal
    ( 2022-01-01)
    Padmanathan S.
    ;
    Azremi Abdullah Al-Hadi
    ;
    Elshirkasi A.M.
    ;
    Al-Bawri S.S.
    ;
    Islam M.T.
    ;
    Sabapathy T.
    ;
    Jusoh M.
    ;
    Akkaraekthalin P.
    ;
    Soh P.J.
    In this paper, the design of a multiband multiple-input multiple-output (MIMO) antenna with frequency and radiation pattern reconfiguration capability in the 5G sub-6 GHz band is presented. Frequency and radiation pattern reconfiguration are enabled on the antenna consisting of two planar inverted-F antenna (PIFA) elements using PIN diodes and DC biasing circuits. At the reflection coefficients of less than -6 dB, both PIFA element 1 and PIFA element 2 achieves triband with bandwidth from 220 MHz to 2330 MHz, ranging from 0.8 GHz to 6 GHz, covering cellular bands for GSM, UMTS, LTE and 5G-NR bands. Moreover, high isolation of at least -10 dB and envelope correlation coefficient with less than 0.3 between ports ensures satisfactory MIMO diversity performance. PIFA elements 1 and 2 have achieved main lobe gain ranging from 1.06 dB to 2.97 dB at their respective resonant frequencies with total efficiencies ranging from 46.2% to 74.5% achieved within the operating bandwidth. This enables a calculated channel capacity of 9.45 to 10.5 bit/s/Hz for PIFA element 1 and 9.56 to 10.23 bit/s/Hz for PIFA element 2, respectively. The percentage of channel capacity achieved over IID capacity for both PIFA elements ranges from 73.71% to 92.8%. Simulated antenna performance parameters agreed well with measurements, and potentially enables reliable and consistent data throughput for 5G mobile terminals.
