Syed Akhmal Syed Jamalil
Thumbnail Image
Preferred name
Syed Akhmal Syed Jamalil
Official Name
Syed Akhmal, Syed Jamalil
Alternative Name
Jamalil, Syed Akhmal B.Syed
Syed Jamalil, Syed A.
Syed Jamalil, S.A.
Akhmal, S.
Main Affiliation
Scopus Author ID
55831869200

Research Output

Filters

3 1
1
3
Reset filters

Settings
Now showing 1 - 3 of 3
  • Publication
    Development of detachable Rogowski Coil current sensor using PCB for High Voltage cable partial discharge measurement
    ( 2022-01-01)
    Syed Akhmal Syed Jamalil
    ;
    Muzamir Isa
    ;
    Ahmad Zaidi Abdullah
    ;
    Ayob Nazmy Nanyan
    ;
    Bohari Z.H.
    Insulation failure in High Voltage (HV) cables is evaluated using a variety of monitoring techniques. Previous silicon technologies were outperformed by wide-bandgap semiconductor power devices with faster switching speeds. Their precise current management or current protection measures must be upgraded. As a result, their precise current control or protection measures have become more sophisticated. The traditional Rogowski Coil (RC) with the magnetic core, on the other hand, has low measurement accuracy, a short measuring range, and is difficult to fabricate. This paper presents and discusses the development of a Rogowski Coil using a detachable Printed Circuit Board (PCB) as a current sensor for Partial Discharge (PD) measurement. Furthermore, the development of this innovative current sensor concentrated on the detachable PCB Rogowski Coil's capability to measure as a high-voltage (HV) current sensor and its sensitivity in fault diagnosis, over-voltage current sensing, and high-impulse current sensing on HV cables. The experimental design, techniques, and measurement parameters used in models were discussed. Finally, a brief analysis of the detachable PCB RC current sensor such as sensitivity, maximum voltage and current detection is presented. This paper can also be used as a guideline for other researchers to develop an advanced RC current sensor using PCB as a HV current sensor in the future. The measurement results of the detachable PCB RC current sensor such as the sensitivity and current detection signal can also be used as a guideline by another researcher. As a result, the goal of this project is to measure PD on HV cables using an RC current sensor by utilising PCB technology.
      2  40
  • Publication
    Develop portable blood analyzer based on temperature and quantity level
    (IOP Publishing, 2020)
    Muhammad Amar Farhan Sukemi
    ;
    Wan Azani Wan Mustafa
    ;
    Muhammad Zaid Aihsan
    ;
    Zol Bahri Razali
    ;
    Syed Akhmal Syed Jamalil
    ;
    Syahrul Affandi Saidi
    This technical paper presents a developing portable blood analyzer for monitoring of human blood sample. Perseverance of blood sample in hospitals is important in order to obtain a great quality of blood and therefore it able to determining the human type of disease. This is a life-threatening early step in most medical applications fields such as diagnosis, treatment and medical research. The proposed system consists of three main parts. In the first part, the use of convenient and handy device to deal with the problem of incorrect temperature value and inadequate quantity of blood sample. Most of previous human hospitality services show a fail to handle and properly in time to take human blood sample for diagnosis in a schedule time frame such as not punctual in taking blood sample from a patient in three different times in one day. The consequences is that these blood sample are not in perfect quality for a correct estimation of the human disease towards a pathology unit. The proposed method is a device that uses infrared temperature system and non-contact blood sample quantity detection. In the second part is by combining those two approaches to single programmable electronic modules that are used to minimize the size of the portable device in the resulting techniques to improve the functionality. The third part is accomplished by using a modern technique to produce an interface to provide the value of human blood sample and shows it on display for monitoring purposes. The programmable coding has been test in several different types of sensors and physical part. The experimental results show that this method able to integrate both requirement of human blood sample perseverance with a contactless method towards a blood tube, providing the output value of quality characteristic in a display and making it well-suited for a convenient practical application system. The experimental results in real time applications shows the effectiveness, reliable and efficiency in the proposed approach which able to almost accurately detect and monitor the human blood sample with the ability to detect different types of people gender and blood type. The proposed coding system can be executed at more precise time scheduling which is better than real life human monitoring system.
      1  29
  • Publication
    Development of Second Order High Frequency Filter for Partial Discharge Measurement
    ( 2024-11-01)
    Syed Akhmal Syed Jamalil
    ;
    Shamsul Z.
    ;
    Muzamir Isa
    ;
    Ahmad Zaidi Abdullah
    ;
    Nanyan A.N.
    Partial Discharge (PD) can occur on any high-voltage equipment. This study is particularly concerned with the PD that occurs on underground cables. Researchers frequently struggle to isolate interference noise from the PD signal when doing PD measurements. Therefore, to reduce the interference noise during PD measurements, Sallen-Key High Pass Filter (HPF) with a 500 kHz, or a little bit higher cut-off frequency are designed. This filter is designed with a designated cut-off frequency value because the frequency range of the PD signal is between 1 MHz to 1 GHz. Based on the results of experimental testing for actual filters, the designed filter is a HPF with a cut-off frequency of 500 kHz. When the generator function's input frequency values are set between 500 kHz and 2.4 MHz, the signal will pass the filter and provide output values for both frequencies and amplitude. However, at frequencies lower than 500 kHz, the signal is beginning to be filtered and the output signal's amplitude is getting close to zero. Based on the PD testing results, there is interference on the PD signal shown on the oscilloscope when a 1kV supply is applied to an underground cable without using a filter. But, when the proposed filter is used in PD testing, the ripple voltage is reduced from 123 mV to 67 mV. This proves that when the designed HPF is used in PD testing, it can reduce interference noise on the PD signal.
      30  2
